Here you can see a list of all the modules a short description and the state of development.
| module | short description | issues & wishes | state of development |
|---|---|---|---|
 | Two automatic volume knobs: make a signal louder or quieter * ∑ mix both channels | range does not feel right yet. | working ok |
 | Offset (=shift) signal Set Gain of Signal offset and scale your signal or use as signal source Use only the output as a cv source * Keep knobs at center position to leave signal unaffected | noisy. truly ugly front plate | working ok |
 | slows down the rate of change of a signal control rate of rise and rate of fall independently switch to change shape * create envelopes or portamento | done ✅ | |
 | MIX: set mode switches to default setting to use as a mixer. use individual outputs to ATTENUATE signals (= make signal smaller / quieter). * use x input to chain | – | done ✅ |
 | same as 4MIX, but I prefer faders | – | done ✅ |
 | patch a fast waveform here and LISTEN. Use minijack for big speakers | ? | done ✅ |
 | bridge to minijack and interface CANVAS to other gear use as input or output set ground reference by switch. try different settings and see outcome | – | done ✅ |
 | bring in some audio from outside. minijack audio input. | done ✅ | |
 | divide clock two different dividers: upper unit divides clock by the powers of two: 2, 4, 8, 16, 32, 64 lower unit divides Clock by 10, stepping through the outputs connect any output to RESet input to shorten length * RESET and CLOCK one divider from the other one and get to polyrhythmic lands | done ✅ | |
 | generate a sequence use knobs to change CV of steps use switches to change GATE and TRIG sequence patch step-output to reset input to limit sequence length and loop the sequencer | not all step gate outputs reset seq | done ✅ |
 | split ways of a signal use in any direction 2 copies | done ✅ | |
 | 4 submodules: AND outputs a GATE if both inputs get a GATE OR outputs a GATE if either of inputs gets a GATE NOT outputs if its input gets no GATE LATCH can output a GATE. Use inputs to turn ON and OFF | latch input not rail-to-rail compatible | working ok |
 | SEE waveforms on display or TUNE your oscillators use HOLD to make it stop switching around Use the 2.5V reference to calibrate some modules If you ever need a GND (0V) connection here you go. | no note names shown in tuner | mostly working |
 | introduce harmony get oscillators to play well tempered musical notes. connect its output to VCO v/oct input 3 interdependent channels of CV quantization Use Complexity to add or remove harmonic richness of played notes. Use Harmony to change the scale degree (scale-step theory / Stufentheorie) choose scale using small knob TRIG outputs on change of note * Patch a faster sequence to any channel and a slower one to the harmony input. | 3 voices not cooperating | working ok |
 | randomly evolving CV and GATE sequencer set rate and flavor of change on knob or by CV input needs clock signal to work connect CV to DENSity input to change amount of active steps hold KEEP at power up to limit sequence to 8 steps | firmware issues should have internal clock if no input | working ok |
 | delay line: keeps audio in memory and outputs it after some time adjust duration by knob and CV * patch feedback, maybe even using VCA * use WHARP Input for special fx | done ✅ | |
 | the oscillator, the heart of your system. tasty raw waveforms to mess with Patch a sequence to one of the V/OCT inputs. determines the pitch of the oscillator use switch to select range: audio or Low Frequency (LFO) Use TRIG inputs to SYNC multiple oscillators | frequency knob range faulty | working ok |
 | filter waveforms to remove Frequencies Add harmonics using input Drive and Resonance * Patch V/Oct signal and engage full resonance to get sine wave VCO | done ✅ | |
 | four Submodules to manipulate trigger signals: delay trigs, affect delay time by knob and CV randomize trigs, affect probability by knob and CV multiply trigs: x2 / x3 / x4 / x5 / x7 have some digital LOFI NOISE | minor firmware tweaks | working ok |
 | LOFI sampler RECord audio and PLAY it back adjust playback SPEED freeze playback to stutter use low pass filter to make output less harsh | faulty circuit | not working |
 | use joystick and button to control anything use small knobs to attenuate signal | done ✅ | |
 | get some drums going adjust pitch and decay | decay control still not working | partly working |
 | 3 low frequency sine oscillators in phase | CV-input inverted | working ok |
| KEYS | design incomplete |
